1. What is Network Packet Loss?

• Extremely slow web page loading
• Lag and high latency in video conferences
• Interrupted file transfers or failed downloads
• High gaming latency and character teleportation

2. Where Does Packet Loss Occur?

Common Causes by Location:

• Local Devices (e.g., PC, network card): Driver anomalies, aging network cards, or resource exhaustion.
• Access Layer (switches): Port congestion, broadcast storms, or loops.
• Distribution/Core Layers: High CPU usage in devices, abnormal interface transmission/reception.
• Firewalls: ACL or policy misinterceptions, resource bottlenecks.
• Exit Links: Poor ISP-side quality with severe packet loss.
• Cloud Services: Packet loss on the cloud side (beyond user control).

3. How to Distinguish “True Packet Loss” from “False Packet Loss”?

• Firewalls or ACLs blocking ICMP do not mean service packets are truly lost.
• Packet loss at an intermediate hop but normal destination access does not indicate real loss.
• Brief network jitters (e.g., link convergence) may cause transient loss, not stability issues.

• Persistent (not sporadic)
• Consistent across multiple tools (ping, iperf, packet capture)
• Stable and reproducible loss location

4. What Are the Common Detection Tools?

1. ping
   The most basic packet loss testing tool. Sends ICMP packets to check round-trip normality.
   bash

   ping 192.168.1.1 -t          # Continuous ping
   ping -n 50 8.8.8.8          # 50 ping attempts

   Note: ICMP blocking on some devices does not mean network disconnection.
2. tracert/traceroute
   Determines at which hop data starts dropping.
   bash

   tracert www.baidu.com       # Windows
   traceroute www.baidu.com    # Linux

3. iperf
   A professional performance test tool supporting UDP packet loss detection for higher accuracy.
   bash

   iperf3 -c 192.168.1.100 -u -b 10M -t 10  # UDP test at 10Mbps for 10s

4. Packet Capture (Wireshark/tcpdump)
   The core verification method to check if data is sent and acknowledged.

5. What Causes Network Packet Loss?

1. Bandwidth Saturation (Congestion-Induced Loss)

• Principle: Interfaces cannot process excessive data, so full buffers force packet dropping.
• Common scenarios:
  • Massive traffic (e.g., backups, video transfers) exceeding port bandwidth.
  • Cross-VLAN access saturating the core switch’s uplink port.
• Judgment methods:
  • Check interface bandwidth utilization (e.g., display interface).
  • Monitor port traffic (e.g., display counters interface).

2. Interface Errors and Physical Issues

• Symptoms: Loose patch cables, poor optical module contact, or incorrect twisted-pair wiring can cause intermittent loss.
• Key indicators:
  • CRC errors (cyclic redundancy check)
  • Input/Output drops
• Troubleshooting suggestions:
  • Check error packet statistics via display interface brief.
  • Re-plug patch cables or test with new twisted-pair wires.

3. High CPU/Memory Usage

• Insufficient device processing capacity leads to loss.
• Common in:
  • High master control pressure in multi-device stacking.
  • Firewalls crashing under concurrent policies, NAT, and sessions.
  • Routers with 飙升 CPU affecting forwarding capability.
• Troubleshooting methods:
  • Check device CPU usage (display cpu-usage).
  • Verify excessive forwarding entries (e.g., ARP table, MAC table).

4. Broadcast Storms/Loop Issues

• Typical symptoms: Widespread network outages, including failed management port pings.
• Investigation directions:
  • Check if STP is enabled and loop protection is effective.
  • Capture packets for excessive repeated broadcasts (storm).

5. Policy Misinterceptions (ACL, Firewall)

• Sometimes perceived as “loss,” but traffic is actually rejected by policies.
• Checkpoints:
  • Verify if ACL rules allow the traffic.
  • Confirm firewall discard policies.
• Case example: A client experienced server timeouts due to a switch ACL blocking TCP port 443 (HTTPS).

6. Scientific Troubleshooting Logic: A Flowchart

[Terminal Loss?]
↳ Check local NIC drivers, utilization, ARP
[Access Layer Loss?]
↳ Check port traffic, CRC, MAC learning
[Distribution/Core Layer Loss?]
↳ Check link load, policy configuration, NAT forwarding
[Exit Loss?]
↳ ISP line quality, SLA, external speed tests
[Application Layer Misjudgment?]
↳ Application bugs, session control, short timeouts

7. High-Frequency Packet Loss Scenarios and Case Summaries

Case 1: Intermittent Loss During Link Instability

• Symptoms: 50% ping success rate, slow web loading.
• Causes:
  • Loose network cables
  • Interface negotiation anomalies (Gigabit vs. 100Mbps)
  • Firewall ICMP Flood protection limiting responses
• Solutions:
  • Replace cables, ensure consistent negotiation.
  • Adjust firewall policies to relax ICMP detection frequency.

Case 2: Post-Power-On Switch Communication Failure

• Symptoms: Switch cannot ping any host for minutes after startup.
• Causes:
  • Configuration loading time during startup
  • STP (Spanning Tree) not converged, ports in blocking state
• Solutions:
  • Use spanning-tree portfast (Cisco) or stp edged-port enable (Huawei) to accelerate port activation.
  • Test after STP fully converges.

Case 3: Five-port Switch Only Supports Four Ports

• Symptoms: One port fails when the fifth is plugged in.
• Causes:
  • Inadequate power supply
  • Aging chip or hardware failure
• Solutions:
  • Replace the switch.
  • Test chip power supply and current fluctuations with professional tools.

Case 4: Switch “COL” Light On/Flashing, No Communication

• Symptoms: Abnormal port communication, severe loss in packet capture.
• Causes:
  • Collisions! (Indicated by the collision light)
  • Port connected to non-full-duplex devices, negotiation failure
• Solutions:
  • Manually specify consistent duplex modes.
  • Replace cables or outdated devices to avoid incompatibility.

Case 5: Frequent Service Disconnections After Upgrading to Gigabit

• Symptoms: Intermittent server connections on Gigabit links, frequent retransmissions in captures.
• Causes:
  • Inadequate cable/module quality for Gigabit links
  • Unlocked port speed causing unstable negotiation
• Solutions:
  • Use Cat6+ cables.
  • Manually lock to Gigabit full-duplex.
  • Update NIC drivers and switch firmware.

Case 6: Severe Cross-VLAN Communication Loss

• Symptoms: Normal intra-VLAN, but ping loss across VLANs.
• Causes:
  • Incorrect Layer 3 VLAN interface configurations
  • ACLs restricting traffic
  • Stale ARP table entries
• Solutions:
  • Verify VLAN interface IPs, subnets, and routes.
  • Clear ARP cache for re-learning.
  • Capture packets to check ICMP filtering.

8. How to Prevent Packet Loss at the 萌芽 Stage (Bud Stage)?

1. Reliable device selection:
   • Avoid low-end switches in high-concurrency environments.
   • Use QoS- and hardware-forwarding-supported devices for critical nodes.
2. Regular inspection mechanisms:
   • Periodically check CPU, memory, interface traffic, and error packets.
   • Implement SNMP + network management platforms for 7×24 alerting.
3. Site environment considerations:
   • Maintain 机房 (server room) temperature at 20–25°C.
   • Ensure clean power, reliable grounding, and static electricity prevention.
4. Standardized configurations and documentation:
   • Log every modification and rollback plan.
   • Use configuration templates to avoid human errors.
5. Troubleshooting triad + packet capture:
   • Prioritize capturing ARP, ICMP, and TCP handshakes.
   • Use ping + traceroute + iperf in combination.
   • Verify DNS, VLAN, ACL, and routes are error-free.
